1┌─────────────────────────────────────────────────────────┐
2│               Marketing Funnel (AIDA)                    │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│     ████████████████████████████████  Awareness (100%)  │
6│     ██████████████████████           Interest (65%)     │
7│     ████████████████                 Desire (45%)       │
8│     ██████████                       Action (25%)       │
9│                                                          │
10├─────────────────────────────────────────────────────────┤
11│               E-commerce Funnel                          │
12├─────────────────────────────────────────────────────────┤
13│                                                          │
14│     ████████████████████████████████  Visit (100%)      │
15│     ██████████████████████████       View Product (75%) │
16│     ████████████████████             Add to Cart (50%)  │
17│     ██████████████                   Checkout (30%)     │
18│     ████████                         Purchase (18%)     │
19│                                                          │
20├─────────────────────────────────────────────────────────┤
21│               SaaS Signup Funnel                         │
22├─────────────────────────────────────────────────────────┤
23│                                                          │
24│     ████████████████████████████████  Landing (100%)    │
25│     ██████████████████████████       Signup Start (60%) │
26│     ████████████████████             Email Verify (40%) │
27│     ██████████████                   Complete Profile   │
28│     ████████                         First Action (15%) │
29│                                                          │
30└─────────────────────────────────────────────────────────┘

1import pandas as pd
2import numpy as np
3import matplotlib.pyplot as plt
4from datetime import datetime, timedelta
5
6# Generate sample event data
7np.random.seed(42)
8n_users = 10000
9
10# Simulate funnel with drop-off at each stage
11users = list(range(1, n_users + 1))
12events = []
13
14base_date = datetime(2024, 1, 1)
15
16for user_id in users:
17    session_time = base_date + timedelta(days=np.random.randint(0, 90))
18
19    # Stage 1: Landing (100%)
20    events.append({
21        'user_id': user_id,
22        'event': 'landing',
23        'timestamp': session_time
24    })
25
26    # Stage 2: View Product (70%)
27    if np.random.random() < 0.70:
28        session_time += timedelta(seconds=np.random.randint(10, 120))
29        events.append({
30            'user_id': user_id,
31            'event': 'view_product',
32            'timestamp': session_time
33        })
34    else:
35        continue
36
37    # Stage 3: Add to Cart (55%)
38    if np.random.random() < 0.55:
39        session_time += timedelta(seconds=np.random.randint(30, 300))
40        events.append({
41            'user_id': user_id,
42            'event': 'add_to_cart',
43            'timestamp': session_time
44        })
45    else:
46        continue
47
48    # Stage 4: Checkout (60%)
49    if np.random.random() < 0.60:
50        session_time += timedelta(seconds=np.random.randint(60, 600))
51        events.append({
52            'user_id': user_id,
53            'event': 'checkout',
54            'timestamp': session_time
55        })
56    else:
57        continue
58
59    # Stage 5: Purchase (70%)
60    if np.random.random() < 0.70:
61        session_time += timedelta(seconds=np.random.randint(30, 180))
62        events.append({
63            'user_id': user_id,
64            'event': 'purchase',
65            'timestamp': session_time
66        })
67
68events_df = pd.DataFrame(events)
69print(f"Total events: {len(events_df)}")
70print(events_df['event'].value_counts())

1# Define funnel sequence
2funnel_steps = ['landing', 'view_product', 'add_to_cart', 'checkout', 'purchase']
3
4# Create step order mapping
5step_order = {step: i for i, step in enumerate(funnel_steps)}
6events_df['step_order'] = events_df['event'].map(step_order)
7
8# Get max step reached per user
9user_progress = events_df.groupby('user_id').agg({
10    'step_order': 'max',
11    'timestamp': ['min', 'max']
12}).reset_index()
13
14user_progress.columns = ['user_id', 'max_step', 'first_event', 'last_event']
15user_progress['journey_time'] = (user_progress['last_event'] - user_progress['first_event']).dt.total_seconds()
16
17print(user_progress.head())

1def calculate_funnel(events_df, funnel_steps):
2    """Calculate funnel metrics"""
3
4    # Count users at each step
5    user_steps = events_df.groupby('user_id')['event'].apply(set).reset_index()
6
7    results = []
8    for i, step in enumerate(funnel_steps):
9        # Users who reached this step
10        users_at_step = user_steps[user_steps['event'].apply(lambda x: step in x)]
11        count = len(users_at_step)
12
13        # Conversion rates
14        overall_rate = count / len(user_steps) * 100
15        step_rate = count / results[i-1]['count'] * 100 if i > 0 else 100
16
17        results.append({
18            'step': step,
19            'step_number': i + 1,
20            'count': count,
21            'overall_conversion': round(overall_rate, 2),
22            'step_conversion': round(step_rate, 2),
23            'drop_off': round(100 - step_rate, 2) if i > 0 else 0
24        })
25
26    return pd.DataFrame(results)
27
28funnel_df = calculate_funnel(events_df, funnel_steps)
29print("Funnel Analysis:")
30print(funnel_df)

1def plot_funnel(funnel_df):
2    """Create funnel visualization"""
3    fig, axes = plt.subplots(1, 2, figsize=(14, 6))
4
5    # Bar chart
6    bars = axes[0].barh(funnel_df['step'][::-1], funnel_df['count'][::-1])
7    axes[0].set_xlabel('Users')
8    axes[0].set_title('Funnel: User Counts')
9
10    # Add count labels
11    for bar, count in zip(bars, funnel_df['count'][::-1]):
12        axes[0].text(bar.get_width() + 100, bar.get_y() + bar.get_height()/2,
13                     f'{count:,}', va='center')
14
15    # Conversion rate chart
16    x = range(len(funnel_df))
17    axes[1].plot(x, funnel_df['overall_conversion'], marker='o', linewidth=2, label='Overall')
18    axes[1].bar(x, funnel_df['step_conversion'], alpha=0.3, label='Step')
19    axes[1].set_xticks(x)
20    axes[1].set_xticklabels(funnel_df['step'], rotation=45, ha='right')
21    axes[1].set_ylabel('Conversion Rate (%)')
22    axes[1].set_title('Conversion Rates')
23    axes[1].legend()
24    axes[1].set_ylim(0, 105)
25
26    # Add percentage labels
27    for i, (overall, step) in enumerate(zip(funnel_df['overall_conversion'], funnel_df['step_conversion'])):
28        axes[1].text(i, overall + 2, f'{overall}%', ha='center', fontsize=9)
29
30    plt.tight_layout()
31    plt.savefig('funnel_analysis.png', dpi=150)
32    plt.show()
33
34plot_funnel(funnel_df)

1def plot_funnel_pyramid(funnel_df):
2    """Create pyramid-style funnel"""
3    fig, ax = plt.subplots(figsize=(10, 8))
4
5    n_steps = len(funnel_df)
6    max_width = funnel_df['count'].max()
7
8    colors = plt.cm.Blues(np.linspace(0.3, 0.9, n_steps))
9
10    for i, (_, row) in enumerate(funnel_df.iterrows()):
11        width = row['count'] / max_width
12        left = (1 - width) / 2
13
14        rect = plt.Rectangle(
15            (left, n_steps - i - 1),
16            width, 0.8,
17            facecolor=colors[i],
18            edgecolor='white',
19            linewidth=2
20        )
21        ax.add_patch(rect)
22
23        # Labels
24        ax.text(0.5, n_steps - i - 0.6,
25                f"{row['step']}\n{row['count']:,} ({row['overall_conversion']}%)",
26                ha='center', va='center', fontsize=10, fontweight='bold')
27
28        # Drop-off annotation
29        if i > 0:
30            ax.annotate(
31                f"↓ {row['drop_off']}% drop",
32                xy=(0.85, n_steps - i + 0.1),
33                fontsize=9, color='red'
34            )
35
36    ax.set_xlim(0, 1)
37    ax.set_ylim(0, n_steps)
38    ax.axis('off')
39    ax.set_title('Conversion Funnel', fontsize=14, fontweight='bold')
40
41    plt.tight_layout()
42    plt.savefig('funnel_pyramid.png', dpi=150)
43    plt.show()
44
45plot_funnel_pyramid(funnel_df)

1# Add user segments
2np.random.seed(42)
3user_segments = pd.DataFrame({
4    'user_id': range(1, n_users + 1),
5    'device': np.random.choice(['Mobile', 'Desktop', 'Tablet'], n_users, p=[0.55, 0.35, 0.10]),
6    'channel': np.random.choice(['Organic', 'Paid', 'Social', 'Email'], n_users, p=[0.35, 0.30, 0.20, 0.15]),
7    'is_new': np.random.choice([True, False], n_users, p=[0.7, 0.3])
8})
9
10events_df = events_df.merge(user_segments, on='user_id')
11print(events_df.head())

1def funnel_by_segment(events_df, funnel_steps, segment_col):
2    """Calculate funnel for each segment"""
3    results = []
4
5    for segment in events_df[segment_col].unique():
6        segment_data = events_df[events_df[segment_col] == segment]
7        funnel = calculate_funnel(segment_data, funnel_steps)
8        funnel['segment'] = segment
9        results.append(funnel)
10
11    return pd.concat(results, ignore_index=True)
12
13# By device
14device_funnel = funnel_by_segment(events_df, funnel_steps, 'device')
15print("\nFunnel by Device:")
16device_pivot = device_funnel.pivot(index='step', columns='segment', values='overall_conversion')
17print(device_pivot)
18
19# By channel
20channel_funnel = funnel_by_segment(events_df, funnel_steps, 'channel')
21print("\nFunnel by Channel:")
22channel_pivot = channel_funnel.pivot(index='step', columns='segment', values='overall_conversion')
23print(channel_pivot)

1def plot_segment_comparison(funnel_df, segment_col):
2    """Compare funnels across segments"""
3    segments = funnel_df['segment'].unique()
4    n_segments = len(segments)
5
6    fig, ax = plt.subplots(figsize=(12, 6))
7
8    x = np.arange(len(funnel_steps))
9    width = 0.8 / n_segments
10
11    for i, segment in enumerate(segments):
12        segment_data = funnel_df[funnel_df['segment'] == segment]
13        offset = (i - n_segments/2 + 0.5) * width
14        bars = ax.bar(x + offset, segment_data['overall_conversion'],
15                      width, label=segment, alpha=0.8)
16
17    ax.set_ylabel('Conversion Rate (%)')
18    ax.set_title(f'Funnel Comparison by {segment_col}')
19    ax.set_xticks(x)
20    ax.set_xticklabels(funnel_steps, rotation=45, ha='right')
21    ax.legend(title=segment_col)
22    ax.set_ylim(0, 105)
23
24    plt.tight_layout()
25    plt.savefig(f'funnel_by_{segment_col}.png', dpi=150)
26    plt.show()
27
28plot_segment_comparison(device_funnel, 'Device')
29plot_segment_comparison(channel_funnel, 'Channel')

1def calculate_step_times(events_df, funnel_steps):
2    """Calculate time between funnel steps"""
3    # Pivot events to get timestamp for each step per user
4    user_events = events_df.pivot_table(
5        index='user_id',
6        columns='event',
7        values='timestamp',
8        aggfunc='first'
9    )
10
11    # Calculate time differences
12    time_diffs = {}
13    for i in range(len(funnel_steps) - 1):
14        step1 = funnel_steps[i]
15        step2 = funnel_steps[i + 1]
16
17        if step1 in user_events.columns and step2 in user_events.columns:
18            diff = (user_events[step2] - user_events[step1]).dt.total_seconds()
19            time_diffs[f'{step1}_to_{step2}'] = diff.dropna()
20
21    return time_diffs
22
23time_diffs = calculate_step_times(events_df, funnel_steps)
24
25# Summary statistics
26print("Time Between Steps (seconds):")
27for step, times in time_diffs.items():
28    print(f"\n{step}:")
29    print(f"  Median: {times.median():.1f}s")
30    print(f"  Mean: {times.mean():.1f}s")
31    print(f"  95th percentile: {times.quantile(0.95):.1f}s")

1def time_to_convert_analysis(events_df):
2    """Analyze time from first touch to conversion"""
3    # Get first and last events per user
4    user_journey = events_df.groupby('user_id').agg({
5        'timestamp': ['min', 'max'],
6        'event': lambda x: list(x)
7    }).reset_index()
8    user_journey.columns = ['user_id', 'first_event', 'last_event', 'events']
9
10    # Time to convert (for users who purchased)
11    purchasers = user_journey[user_journey['events'].apply(lambda x: 'purchase' in x)]
12    purchasers['time_to_convert'] = (purchasers['last_event'] - purchasers['first_event']).dt.total_seconds()
13
14    # Distribution
15    fig, axes = plt.subplots(1, 2, figsize=(12, 5))
16
17    # Histogram
18    axes[0].hist(purchasers['time_to_convert'] / 60, bins=50, edgecolor='black')
19    axes[0].set_xlabel('Time to Convert (minutes)')
20    axes[0].set_ylabel('Users')
21    axes[0].set_title('Time-to-Convert Distribution')
22    axes[0].axvline(purchasers['time_to_convert'].median() / 60, color='r',
23                    linestyle='--', label=f"Median: {purchasers['time_to_convert'].median()/60:.1f}m")
24    axes[0].legend()
25
26    # Cumulative
27    sorted_times = np.sort(purchasers['time_to_convert'].values) / 60
28    cumulative = np.arange(1, len(sorted_times) + 1) / len(sorted_times) * 100
29    axes[1].plot(sorted_times, cumulative)
30    axes[1].set_xlabel('Time (minutes)')
31    axes[1].set_ylabel('Cumulative % Converted')
32    axes[1].set_title('Cumulative Conversion by Time')
33    axes[1].axhline(50, color='r', linestyle='--', alpha=0.5)
34    axes[1].axhline(80, color='g', linestyle='--', alpha=0.5)
35
36    plt.tight_layout()
37    plt.show()
38
39    return purchasers
40
41purchasers_df = time_to_convert_analysis(events_df)

1def funnel_trend(events_df, funnel_steps, freq='W'):
2    """Calculate funnel metrics over time"""
3    events_df['period'] = events_df['timestamp'].dt.to_period(freq)
4
5    results = []
6    for period in events_df['period'].unique():
7        period_data = events_df[events_df['period'] == period]
8        funnel = calculate_funnel(period_data, funnel_steps)
9        funnel['period'] = period
10        results.append(funnel)
11
12    trend_df = pd.concat(results, ignore_index=True)
13    return trend_df
14
15trend = funnel_trend(events_df, funnel_steps, 'W')
16
17# Plot conversion rate trend
18fig, ax = plt.subplots(figsize=(14, 6))
19
20purchase_trend = trend[trend['step'] == 'purchase'].copy()
21purchase_trend['period'] = purchase_trend['period'].astype(str)
22
23ax.plot(purchase_trend['period'], purchase_trend['overall_conversion'], marker='o')
24ax.set_xlabel('Week')
25ax.set_ylabel('Overall Conversion Rate (%)')
26ax.set_title('Purchase Conversion Rate Over Time')
27ax.tick_params(axis='x', rotation=45)
28
29# Add trend line
30z = np.polyfit(range(len(purchase_trend)), purchase_trend['overall_conversion'], 1)
31p = np.poly1d(z)
32ax.plot(purchase_trend['period'], p(range(len(purchase_trend))), 'r--', label='Trend')
33ax.legend()
34
35plt.tight_layout()
36plt.show()

1def calculate_velocity(events_df, funnel_steps):
2    """Calculate funnel velocity metrics"""
3    metrics = {}
4
5    # Median time per step
6    time_diffs = calculate_step_times(events_df, funnel_steps)
7    metrics['median_step_times'] = {k: v.median() for k, v in time_diffs.items()}
8
9    # Total funnel time
10    total_times = events_df.groupby('user_id').apply(
11        lambda x: (x['timestamp'].max() - x['timestamp'].min()).total_seconds()
12    )
13    metrics['total_funnel_time'] = {
14        'median': total_times.median(),
15        'mean': total_times.mean(),
16        'p75': total_times.quantile(0.75)
17    }
18
19    # Conversion window (time within which X% convert)
20    purchasers = events_df[events_df['event'] == 'purchase']['user_id'].unique()
21    converter_times = total_times[total_times.index.isin(purchasers)]
22
23    metrics['conversion_windows'] = {
24        '50%': converter_times.quantile(0.5),
25        '75%': converter_times.quantile(0.75),
26        '90%': converter_times.quantile(0.90)
27    }
28
29    return metrics
30
31velocity = calculate_velocity(events_df, funnel_steps)
32
33print("Funnel Velocity Metrics:")
34print("\nMedian Time Between Steps (seconds):")
35for step, time in velocity['median_step_times'].items():
36    print(f"  {step}: {time:.1f}s")
37
38print(f"\nTotal Funnel Time:")
39for metric, value in velocity['total_funnel_time'].items():
40    print(f"  {metric}: {value:.1f}s")
41
42print(f"\nConversion Windows:")
43for pct, time in velocity['conversion_windows'].items():
44    print(f"  {pct} of converters complete in: {time:.1f}s")

1def analyze_dropoff(events_df, funnel_steps):
2    """Detailed drop-off analysis"""
3    user_max_step = events_df.groupby('user_id')['step_order'].max().reset_index()
4    user_max_step = user_max_step.merge(
5        events_df[['user_id', 'device', 'channel', 'is_new']].drop_duplicates(),
6        on='user_id'
7    )
8
9    results = {}
10
11    for i, step in enumerate(funnel_steps[:-1]):
12        # Users who dropped at this step
13        dropped = user_max_step[user_max_step['step_order'] == i]
14
15        if len(dropped) > 0:
16            results[step] = {
17                'count': len(dropped),
18                'by_device': dropped['device'].value_counts().to_dict(),
19                'by_channel': dropped['channel'].value_counts().to_dict(),
20                'new_vs_returning': dropped['is_new'].value_counts().to_dict()
21            }
22
23    return results
24
25dropoff = analyze_dropoff(events_df, funnel_steps)
26
27print("Drop-off Analysis:")
28for step, details in dropoff.items():
29    print(f"\n{step.upper()} ({details['count']} users dropped)")
30    print(f"  By Device: {details['by_device']}")
31    print(f"  By Channel: {details['by_channel']}")

1def funnel_health_score(funnel_df, benchmarks=None):
2    """Calculate funnel health score"""
3    if benchmarks is None:
4        # Default benchmarks
5        benchmarks = {
6            'view_product': 75,
7            'add_to_cart': 35,
8            'checkout': 20,
9            'purchase': 15
10        }
11
12    scores = []
13    for _, row in funnel_df.iterrows():
14        if row['step'] in benchmarks:
15            benchmark = benchmarks[row['step']]
16            actual = row['overall_conversion']
17            score = min(100, (actual / benchmark) * 100)
18            scores.append({
19                'step': row['step'],
20                'actual': actual,
21                'benchmark': benchmark,
22                'score': round(score, 1),
23                'status': '✅' if actual >= benchmark else '⚠️' if actual >= benchmark * 0.8 else '❌'
24            })
25
26    health_df = pd.DataFrame(scores)
27    overall_health = health_df['score'].mean()
28
29    print("Funnel Health Report:")
30    print(health_df.to_string(index=False))
31    print(f"\nOverall Health Score: {overall_health:.1f}/100")
32
33    return health_df, overall_health
34
35health_df, overall_score = funnel_health_score(funnel_df)

1-- Count users at each funnel step
2WITH funnel_stages AS (
3    SELECT
4        user_id,
5        MAX(CASE WHEN event = 'landing' THEN 1 ELSE 0 END) AS landing,
6        MAX(CASE WHEN event = 'view_product' THEN 1 ELSE 0 END) AS view_product,
7        MAX(CASE WHEN event = 'add_to_cart' THEN 1 ELSE 0 END) AS add_to_cart,
8        MAX(CASE WHEN event = 'checkout' THEN 1 ELSE 0 END) AS checkout,
9        MAX(CASE WHEN event = 'purchase' THEN 1 ELSE 0 END) AS purchase
10    FROM events
11    GROUP BY user_id
12)
13SELECT
14    SUM(landing) AS landing_users,
15    SUM(view_product) AS view_product_users,
16    SUM(add_to_cart) AS add_to_cart_users,
17    SUM(checkout) AS checkout_users,
18    SUM(purchase) AS purchase_users,
19    ROUND(SUM(view_product) * 100.0 / SUM(landing), 2) AS landing_to_view_rate,
20    ROUND(SUM(add_to_cart) * 100.0 / SUM(view_product), 2) AS view_to_cart_rate,
21    ROUND(SUM(checkout) * 100.0 / SUM(add_to_cart), 2) AS cart_to_checkout_rate,
22    ROUND(SUM(purchase) * 100.0 / SUM(checkout), 2) AS checkout_to_purchase_rate,
23    ROUND(SUM(purchase) * 100.0 / SUM(landing), 2) AS overall_conversion_rate
24FROM funnel_stages;
