1ROLE HIERARCHY
2──────────────
3
4┌─────────────────────────────────────────────────┐
5│                    INSTANCE                     │
6│  ┌─────────────────────────────────────────┐   │
7│  │             GLOBAL OWNER                 │   │
8│  │  • Full system access                    │   │
9│  │  • User management                       │   │
10│  │  • All settings                          │   │
11│  └─────────────────────────────────────────┘   │
12│                      │                          │
13│  ┌─────────────────────────────────────────┐   │
14│  │          GLOBAL ADMIN (Enterprise)       │   │
15│  │  • User management                       │   │
16│  │  • Some settings                         │   │
17│  │  • Access all workflows                  │   │
18│  └─────────────────────────────────────────┘   │
19│                      │                          │
20│  ┌─────────────────────────────────────────┐   │
21│  │              GLOBAL MEMBER               │   │
22│  │  • Create workflows                      │   │
23│  │  • Own credentials                       │   │
24│  │  • Personal settings                     │   │
25│  └─────────────────────────────────────────┘   │
26└─────────────────────────────────────────────────┘

1WORKFLOW PERMISSIONS
2────────────────────
3
4OWNER (per workflow)
5├── Full access
6├── Edit workflow
7├── Execute
8├── Share
9├── Delete
10└── Transfer ownership
11
12EDITOR
13├── View workflow
14├── Edit workflow
15├── Execute
16└── Cannot delete/share
17
18VIEWER (Enterprise)
19├── View only
20├── See executions
21└── Cannot modify

11. Open workflow
22. Click "Share" button (top right)
33. Select users to share with
44. Set permission level:
5   - Editor: Can modify
6   - Viewer: Read only (Enterprise)
75. Save changes

1SHARING MATRIX
2──────────────
3
4Workflow Type       │ Share With    │ Permission
5────────────────────┼───────────────┼────────────
6Production Critical │ Team leads    │ Editor
7                    │ Team members  │ Viewer
8────────────────────┼───────────────┼────────────
9Development         │ Team members  │ Editor
10                    │ Others        │ None
11────────────────────┼───────────────┼────────────
12Utility/Tools       │ All users     │ Viewer
13                    │ Maintainer    │ Editor
14────────────────────┼───────────────┼────────────
15Templates           │ All users     │ Viewer
16                    │ Template team │ Editor

1# Share workflow via API
2curl -X POST \
3  "https://n8n.yourdomain.com/rest/workflows/1/share" \
4  -H "Content-Type: application/json" \
5  -H "X-N8N-API-KEY: your_api_key" \
6  -d '{
7    "shareWith": {
8      "userId": "user-uuid-here",
9      "role": "editor"
10    }
11  }'
12
13# List workflow shares
14curl "https://n8n.yourdomain.com/rest/workflows/1/shares" \
15  -H "X-N8N-API-KEY: your_api_key"

11. Settings → Credentials
22. Select credential
33. Click "Sharing"
44. Add users/workflows
55. Note: Secrets never shown to shared users

1CREDENTIAL SHARING OPTIONS
2──────────────────────────
3
4WORKFLOW-SPECIFIC
5├── Credential only works in specific workflow
6├── Cannot be used in other workflows
7├── Recommended for sensitive data
8└── Example: API key for specific integration
9
10USER-SPECIFIC
11├── Shared user can use in their workflows
12├── Can create new workflows with this credential
13├── Cannot see actual secrets
14└── Example: Shared database connection
15
16EVERYONE (Owner only)
17├── All users can use
18├── Useful for common services
19├── Still cannot see secrets
20└── Example: Company Slack token

1ACTION                   │ Owner │ Shared User
2─────────────────────────┼───────┼─────────────
3View credential name     │  ✅   │     ✅
4Use in workflows         │  ✅   │     ✅
5See secret values        │  ✅   │     ❌
6Edit credential          │  ✅   │     ❌
7Delete credential        │  ✅   │     ❌
8Re-share credential      │  ✅   │     ❌

1PROJECT ORGANIZATION
2────────────────────
3
4📁 Project: Marketing Automations
5│
6├── 👤 Project Admin
7│   ├── Full project access
8│   ├── Manage project members
9│   └── All workflows & credentials
10│
11├── 👥 Project Members
12│   ├── Access project resources
13│   └── Create within project
14│
15├── 📋 Workflows
16│   ├── Email Campaign Handler
17│   ├── Social Media Poster
18│   └── Lead Nurture Sequence
19│
20└── 🔑 Credentials
21    ├── Marketing-Mailchimp
22    ├── Marketing-Twitter
23    └── Marketing-HubSpot

1# Enable projects (Enterprise)
2N8N_ENTERPRISE_FEATURES_ENABLED=true
3
4# Project isolation
5N8N_PROJECT_ISOLATION_MODE=strict
6
7# Project settings
8N8N_DEFAULT_PROJECT_ID=default-project-id

1Marketing Department
2├── Workflows: Marketing-*
3├── Credentials: Marketing-*
4├── Users: marketing-team@company.com
5└── Isolation: Cannot access Sales workflows
6
7Sales Department
8├── Workflows: Sales-*
9├── Credentials: Sales-*
10├── Users: sales-team@company.com
11└── Isolation: Cannot access Marketing workflows
12
13Shared Resources
14├── Workflows: Shared-*
15├── Credentials: Common-*
16├── Users: All departments
17└── Read-only for most

1Production
2├── Limited users (admins only)
3├── Strict credential access
4├── No experimental workflows
5└── Full monitoring
6
7Staging
8├── More users
9├── Test credentials only
10├── Clone of production
11└── Testing allowed
12
13Development
14├── All developers
15├── Personal credentials
16├── Experimentation encouraged
17└── Less restrictions

1Workflow Developers
2├── Create/edit workflows
3├── Use shared credentials
4├── Cannot manage users
5└── Cannot access admin settings
6
7Integration Specialists
8├── Full credential access
9├── Setup external services
10├── Document integrations
11└── Support developers
12
13Platform Admins
14├── User management
15├── Instance settings
16├── Monitoring & logs
17└── Backup management

1# Disable code execution
2N8N_NODES_EXCLUDE="[\"n8n-nodes-base.executeCommand\",\"n8n-nodes-base.code\"]"
3
4# Disable file system access
5N8N_NODES_EXCLUDE="[\"n8n-nodes-base.readBinaryFile\",\"n8n-nodes-base.writeBinaryFile\",\"n8n-nodes-base.readFile\",\"n8n-nodes-base.writeFile\"]"
6
7# Disable SSH
8N8N_NODES_EXCLUDE="[\"n8n-nodes-base.ssh\"]"
9
10# Combined restrictions
11N8N_NODES_EXCLUDE="[\"n8n-nodes-base.executeCommand\",\"n8n-nodes-base.ssh\",\"n8n-nodes-base.readBinaryFile\"]"

1# Allow specific IPs for certain users
2location /api/v1/workflows {
3    # Restrict write operations to office IP
4    limit_except GET {
5        allow 203.0.113.0/24;  # Office IP range
6        deny all;
7    }
8
9    proxy_pass http://n8n:5678;
10}

1-- List all workflow permissions
2SELECT
3    w.name as workflow_name,
4    u.email as owner_email,
5    sw."userId" as shared_with,
6    sw.role as permission
7FROM workflow_entity w
8JOIN "user" u ON w."userId" = u.id
9LEFT JOIN shared_workflow sw ON sw."workflowId" = w.id
10ORDER BY w.name;

1-- List credential sharing
2SELECT
3    c.name as credential_name,
4    c.type as credential_type,
5    u.email as owner,
6    sc."userId" as shared_with
7FROM credentials_entity c
8JOIN "user" u ON c."userId" = u.id
9LEFT JOIN shared_credentials sc ON sc."credentialsId" = c.id
10ORDER BY c.name;

1#!/bin/bash
2# permissions-report.sh
3
4REPORT_DIR="/opt/n8n-reports"
5DATE=$(date +%Y%m%d)
6
7# Workflow permissions
8docker exec n8n-postgres psql -U n8n -d n8n -c "
9COPY (
10    SELECT
11        w.name,
12        u.email as owner,
13        string_agg(su.email, ', ') as shared_with
14    FROM workflow_entity w
15    JOIN \"user\" u ON w.\"userId\" = u.id
16    LEFT JOIN shared_workflow sw ON sw.\"workflowId\" = w.id
17    LEFT JOIN \"user\" su ON sw.\"userId\" = su.id
18    GROUP BY w.id, u.id
19) TO STDOUT WITH CSV HEADER;
20" > "$REPORT_DIR/workflow_permissions_$DATE.csv"
21
22echo "Report saved: $REPORT_DIR/workflow_permissions_$DATE.csv"

1HIGH SECURITY (Finance/HR)
2├── Isolated network
3├── Admin access only
4├── Strict credential handling
5├── Full audit logging
6└── Separate backups
7
8STANDARD (General Business)
9├── Team access
10├── Department credentials
11├── Standard monitoring
12└── Regular backups
13
14DEVELOPMENT (Sandbox)
15├── All developers
16├── Test credentials only
17├── Relaxed policies
18└── Optional backups

1# webhook-based communication
2# High-security instance exposes limited webhooks
3# Standard instance calls these webhooks
4
5# Example: HR workflow calls Finance for budget check
6# HR Instance (caller)
7- HTTP Request node
8  - URL: https://finance.n8n.company.com/webhook/budget-check
9  - Auth: Bearer token (shared secret)
10  - Data: { "department": "HR", "amount": 5000 }
11
12# Finance Instance (receiver)
13- Webhook node
14  - Auth: Header auth (validate token)
15  - Respond with approval/denial only

1Error: "You don't have permission"
2
3Check:
41. Is workflow shared with you?
52. What's your permission level?
63. Is credential accessible?
7
8Fix:
9- Ask owner to share
10- Check credential sharing
11- Verify not disabled user

1Error: "Credential not found"
2
3Possible causes:
41. Credential not shared
52. Credential deleted
63. Credential for different workflow
7
8Fix:
9- Request credential sharing
10- Create personal credential
11- Check workflow-specific credentials

1-- Check user's accessible workflows
2SELECT w.name, w.active
3FROM workflow_entity w
4WHERE w."userId" = 'user-uuid'
5   OR EXISTS (
6       SELECT 1 FROM shared_workflow sw
7       WHERE sw."workflowId" = w.id
8       AND sw."userId" = 'user-uuid'
9   );
