1┌─────────────────────────────────────────────────────────┐
2│                    Timeline                              │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│  Event Time:      [E1]----[E2]----[E3]----[E4]          │
6│  (When event      10:00   10:01   10:02   10:03         │
7│   occurred)                                              │
8│                                                          │
9│  Processing Time: [E1]--[E3]----[E2]------[E4]          │
10│  (When event      10:05  10:06   10:08    10:10         │
11│   was processed)                                         │
12│                                                          │
13│  Note: Events can arrive out of order!                   │
14│                                                          │
15└─────────────────────────────────────────────────────────┘

1# Why it matters
2# Event at 10:00 might arrive at 10:05 due to network delay
3# If you compute "sales in last 5 minutes" at 10:06:
4# - Processing time: might miss events still in transit
5# - Event time: correct result based on when sales actually happened

1┌─────────────────────────────────────────────────────────┐
2│                   Windowing Types                        │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│  TUMBLING WINDOW (Fixed, non-overlapping)               │
6│  |----W1----|----W2----|----W3----|                     │
7│  |  E1 E2   |  E3 E4   |  E5 E6   |                     │
8│                                                          │
9│  SLIDING WINDOW (Overlapping)                           │
10│  |----W1----|                                            │
11│       |----W2----|                                       │
12│            |----W3----|                                  │
13│                                                          │
14│  SESSION WINDOW (Activity-based)                        │
15│  |---Session1---|  gap  |--Session2--|  gap  |--S3--|   │
16│                                                          │
17└─────────────────────────────────────────────────────────┘

1# Tumbling Window: 5-minute windows
2# Events [10:00-10:05) go to Window 1
3# Events [10:05-10:10) go to Window 2
4# No overlap
5
6# Sliding Window: 5-minute window, sliding every 1 minute
7# Window 1: [10:00-10:05)
8# Window 2: [10:01-10:06)
9# Events can be in multiple windows
10
11# Session Window: Based on activity
12# Gap of 30 minutes creates new session
13# User activity from 10:00-10:15, then 11:00-11:30
14# = 2 separate sessions

1# Watermark = How long to wait for late data
2
3# Example: Watermark of 10 minutes
4# At processing time 10:20:
5# - Watermark = 10:10 (10:20 - 10 minutes)
6# - Events before 10:10 are considered "late"
7# - Events after 10:10 are still accepted
8
9# Trade-off:
10# - Longer watermark = More complete results, higher latency
11# - Shorter watermark = Faster results, might miss late data

1# Stream processing often needs state
2# Examples:
3# - Running counts
4# - Session information
5# - Aggregations within windows
6
7# Challenges:
8# 1. State can grow unboundedly
9# 2. Need fault tolerance (checkpointing)
10# 3. State must be distributed

1┌─────────────────────────────────────────────────────────┐
2│                  Lambda Architecture                     │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│                    ┌──────────┐                         │
6│                    │  Data    │                         │
7│                    │  Source  │                         │
8│                    └────┬─────┘                         │
9│                         │                                │
10│            ┌────────────┼────────────┐                  │
11│            │            │            │                  │
12│            v            │            v                  │
13│     ┌──────────┐        │     ┌──────────┐             │
14│     │  Batch   │        │     │  Speed   │             │
15│     │  Layer   │        │     │  Layer   │             │
16│     │ (Hadoop) │        │     │ (Storm)  │             │
17│     └────┬─────┘        │     └────┬─────┘             │
18│          │              │          │                    │
19│          v              │          v                    │
20│     ┌──────────┐        │     ┌──────────┐             │
21│     │  Batch   │        │     │ Real-time│             │
22│     │  Views   │        │     │  Views   │             │
23│     └────┬─────┘        │     └────┬─────┘             │
24│          │              │          │                    │
25│          └──────────────┼──────────┘                    │
26│                         │                                │
27│                    ┌────▼────┐                          │
28│                    │ Serving │                          │
29│                    │  Layer  │                          │
30│                    └─────────┘                          │
31│                                                          │
32└─────────────────────────────────────────────────────────┘

1┌─────────────────────────────────────────────────────────┐
2│                  Kappa Architecture                      │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│         ┌──────────┐                                    │
6│         │  Data    │                                    │
7│         │  Source  │                                    │
8│         └────┬─────┘                                    │
9│              │                                           │
10│              v                                           │
11│         ┌──────────┐                                    │
12│         │  Stream  │  (Kafka)                           │
13│         │  Storage │                                    │
14│         └────┬─────┘                                    │
15│              │                                           │
16│              v                                           │
17│         ┌──────────┐                                    │
18│         │  Stream  │  (Spark Streaming, Flink)          │
19│         │ Processor│                                    │
20│         └────┬─────┘                                    │
21│              │                                           │
22│              v                                           │
23│         ┌──────────┐                                    │
24│         │ Serving  │                                    │
25│         │  Layer   │                                    │
26│         └──────────┘                                    │
27│                                                          │
28└─────────────────────────────────────────────────────────┘

1┌─────────────────────────────────────────────────────────┐
2│                 Delivery Guarantees                      │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│  AT-MOST-ONCE                                           │
6│  - Message processed 0 or 1 time                        │
7│  - Fire and forget                                      │
8│  - Data loss possible                                   │
9│  - Use: Metrics where some loss OK                      │
10│                                                          │
11│  AT-LEAST-ONCE                                          │
12│  - Message processed 1 or more times                    │
13│  - Retry on failure                                     │
14│  - Duplicates possible                                  │
15│  - Use: When idempotent operations                      │
16│                                                          │
17│  EXACTLY-ONCE                                           │
18│  - Message processed exactly 1 time                     │
19│  - Most complex to achieve                              │
20│  - No data loss, no duplicates                          │
21│  - Use: Financial transactions                          │
22│                                                          │
23└─────────────────────────────────────────────────────────┘

1# Strategies:
2
3# 1. Idempotent Operations
4# Same operation applied multiple times = same result
5# INSERT becomes UPSERT
6# Count becomes "set count to X"
7
8# 2. Transactional Processing
9# Producer commits offset only after successful processing
10# Uses transaction IDs
11
12# 3. Deduplication
13# Assign unique ID to each message
14# Check if ID already processed

1# Store events, not state
2# State = replay all events
3
4# Example: Bank Account
5events = [
6    {"type": "deposit", "amount": 100, "time": "10:00"},
7    {"type": "withdraw", "amount": 30, "time": "10:05"},
8    {"type": "deposit", "amount": 50, "time": "10:10"},
9]
10
11# Current balance = replay events
12# 0 + 100 - 30 + 50 = 120
13
14# Benefits:
15# - Complete audit trail
16# - Can reconstruct state at any point
17# - Easy debugging

1┌─────────────────────────────────────────────────────────┐
2│                        CQRS                              │
3├─────────────────────────────────────────────────────────┤
4│                                                          │
5│  Commands (Write)          Queries (Read)               │
6│       │                         │                        │
7│       v                         v                        │
8│  ┌─────────┐              ┌─────────┐                   │
9│  │  Write  │              │  Read   │                   │
10│  │  Model  │              │  Model  │                   │
11│  └────┬────┘              └────▲────┘                   │
12│       │                        │                        │
13│       │     Events Stream      │                        │
14│       └────────────────────────┘                        │
15│                                                          │
16└─────────────────────────────────────────────────────────┘

1# Stream-Stream Join
2# Join two event streams within a time window
3
4# Example: Match clicks with impressions
5# Click stream: user_id, ad_id, click_time
6# Impression stream: user_id, ad_id, impression_time
7
8# Join within 10-minute window
9# Find clicks that happened within 10 minutes of impression
10
11# Stream-Table Join
12# Enrich stream with reference data
13
14# Example: Enrich orders with customer info
15# Order stream + Customer table
16# Every order gets customer details

1# Kafka Streams
2# - Already using Kafka
3# - JVM-based applications
4# - Lightweight streaming
5
6# Spark Structured Streaming
7# - Already using Spark
8# - Unified batch + stream
9# - Complex transformations
10
11# Apache Flink
12# - True event-time processing
13# - Very low latency needed
14# - Complex event processing
15
16# Cloud Services
17# - AWS Kinesis
18# - Azure Stream Analytics
19# - Google Dataflow

1import time
2from collections import deque
3from datetime import datetime
4import random
5
6class SimpleStreamProcessor:
7    """Simulate stream processing concepts"""
8
9    def __init__(self, window_size_seconds=5):
10        self.window_size = window_size_seconds
11        self.events = deque()
12        self.watermark = None
13
14    def process_event(self, event):
15        """Process incoming event"""
16        event_time = event['timestamp']
17        value = event['value']
18
19        # Add to window
20        self.events.append(event)
21
22        # Remove old events (tumbling window)
23        cutoff = datetime.now().timestamp() - self.window_size
24        while self.events and self.events[0]['timestamp'] < cutoff:
25            self.events.popleft()
26
27        # Compute window aggregate
28        if self.events:
29            window_sum = sum(e['value'] for e in self.events)
30            window_count = len(self.events)
31            print(f"Window: count={window_count}, sum={window_sum}, avg={window_sum/window_count:.2f}")
32
33    def simulate_stream(self, duration_seconds=30):
34        """Simulate streaming events"""
35        start = time.time()
36
37        while time.time() - start < duration_seconds:
38            # Generate random event
39            event = {
40                'timestamp': datetime.now().timestamp(),
41                'value': random.randint(1, 100)
42            }
43
44            print(f"\nReceived event: value={event['value']}")
45            self.process_event(event)
46
47            # Sleep random interval
48            time.sleep(random.uniform(0.5, 1.5))
49
50
51# Demo
52processor = SimpleStreamProcessor(window_size_seconds=5)
53processor.simulate_stream(duration_seconds=20)

1from datetime import datetime, timedelta
2from collections import defaultdict
3
4class WindowedAggregator:
5    """Tumbling window aggregation"""
6
7    def __init__(self, window_minutes=1):
8        self.window_minutes = window_minutes
9        self.windows = defaultdict(list)
10
11    def get_window_key(self, timestamp):
12        """Get window key for timestamp"""
13        dt = datetime.fromtimestamp(timestamp)
14        # Round down to window boundary
15        minute_bucket = (dt.minute // self.window_minutes) * self.window_minutes
16        window_start = dt.replace(minute=minute_bucket, second=0, microsecond=0)
17        return window_start.isoformat()
18
19    def add_event(self, event):
20        """Add event to appropriate window"""
21        window_key = self.get_window_key(event['timestamp'])
22        self.windows[window_key].append(event)
23
24        # Check if window should be emitted
25        self.emit_completed_windows()
26
27    def emit_completed_windows(self):
28        """Emit aggregates for completed windows"""
29        current_time = datetime.now()
30        current_window = self.get_window_key(current_time.timestamp())
31
32        for window_key in list(self.windows.keys()):
33            if window_key < current_window:
34                events = self.windows[window_key]
35                total = sum(e['value'] for e in events)
36                count = len(events)
37
38                print(f"Window [{window_key}] completed: count={count}, sum={total}")
39                del self.windows[window_key]
40
41
42# Usage example
43agg = WindowedAggregator(window_minutes=1)
44
45# Simulate events
46import time
47import random
48
49for i in range(20):
50    event = {
51        'timestamp': datetime.now().timestamp(),
52        'value': random.randint(10, 50),
53        'event_id': i
54    }
55    print(f"Event {i}: value={event['value']}")
56    agg.add_event(event)
57    time.sleep(0.5)

1# Scenario: E-commerce real-time analytics
2#
3# Events:
4# - page_view: {user_id, page, timestamp}
5# - add_to_cart: {user_id, product_id, timestamp}
6# - purchase: {user_id, order_id, amount, timestamp}
7#
8# Requirements:
9# 1. Real-time dashboard: Active users (last 5 min)
10# 2. Alert: Cart abandonment (add_to_cart without purchase in 30 min)
11# 3. Metric: Revenue per hour
12#
13# Design:
14# - What windowing strategy for each?
15# - What state needs to be maintained?
16# - What delivery guarantee needed?
17
18# YOUR DESIGN HERE
